1 1/2" BSPP Female x 1 - 1/2" 1-Piece M/S Non-Skive Tail - 90° Swept
$398.24
Skip to product information
1 1/2" BSPP Female x 1 - 1/2" 1-Piece M/S Non-Skive Tail - 90° Swept
$398.24
inc GST
Shipping calculated at checkout.
1 1/2" BSPP Female x 1 - 1/2" 1-Piece M/S Non-Skive Tail - 90° Swept
- Part number: J051-2424
- Series: J051 - BSPP Female 90° Swept x MS355/MS360 1-Piece M/S
- Thread: BSP
Specifications
| Thread / fitting type | BSPP FEMALE |
|---|---|
| Thread size & pitch | 1 1/2" - 11 |
| Nominal pipe size | 1 1/2" |
| Thread physical OD/ID 'D' (mm) | 44.86 |
| Suits hose ID | 1 1/2" |
| Cut-off allowance LC (mm) | 113.6 |
| Hex H2 (mm) | 55 |
Specifications from the BOA 1-Piece Fittings catalogue.
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
