1 - 3/16" ORFS Male Straight x 3/4" 1-Piece 1 & 2-Wire Tail
$73.15
Skip to product information
1 - 3/16" ORFS Male Straight x 3/4" 1-Piece 1 & 2-Wire Tail
$73.15
inc GST
Shipping calculated at checkout.
1 - 3/16" ORFS Male Straight x 3/4" 1-Piece 1 & 2-Wire Tail
- Part number: K040-1912
- Series: K040 - ORFS Male x 1-2 Wire 1-Piece Tail
- Thread: ORFS
Specifications
| Thread / fitting type | ORFS MALE |
|---|---|
| Thread size & pitch | 1. 3/16 - 12 |
| Nominal pipe size | 3/4" |
| Thread physical OD/ID 'D' (mm) | 30.22 |
| Suits hose ID | 3/4" |
| Cut-off allowance LC (mm) | 33.8 |
Specifications from the BOA 1-Piece Fittings catalogue.
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
