1" ORFS Female Straight x 3/4" 1-Piece M/S Non-Skive Tail
$100.32
inc GST
Shipping calculated at checkout.
1" ORFS Female Straight x 3/4" 1-Piece M/S Non-Skive Tail
- Part number: J013-1612
- Series: J013 - ORFS Female x MS355/MS360 1-Piece M/S Non-Skive Tail
- Thread: ORFS
Specifications
| Thread / fitting type | ORFS FEMALE |
|---|---|
| Thread size & pitch | 1" - 14 |
| Thread physical OD/ID 'D' (mm) | 23.62 |
| Suits hose ID | 3/4" |
| Cut-off allowance LC (mm) | 41.8 |
| Hex H2 (mm) | 30 |
Specifications from the BOA 1-Piece Fittings catalogue.
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
