13/16" ORFS Female 45° Swept x 3/8" 1-Piece M/S Non-Skive Tail
$98.84
Skip to product information
13/16" ORFS Female 45° Swept x 3/8" 1-Piece M/S Non-Skive Tail
$98.84
inc GST
Shipping calculated at checkout.
13/16" ORFS Female 45° Swept x 3/8" 1-Piece M/S Non-Skive Tail
- Part number: J063-1306
- Series: J063 - ORFS Female 45° Swept x MS355/MS360 1-Piece M/S
- Thread: ORFS
Specifications
| Thread / fitting type | ORFS FEMALE |
|---|---|
| Thread size & pitch | 13/16 - 16 |
| Thread physical OD/ID 'D' (mm) | 19.05 |
| Suits hose ID | 3/8" |
| Cut-off allowance LC (mm) | 41.2 |
| Hex H2 (mm) | 24 |
Specifications from the BOA 1-Piece Fittings catalogue.
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
