26 mm DKOL Female Metric Light 90° Swept x 5/8" 1-Piece 1 & 2-Wire Tail
- Part number: K086-2610
- Series: K086 - DKOL Female Metric Light 90° Swept x 1-2 Wire 1-Piece Tail
- Thread: Metric
Specifications
| Thread / fitting type | DKOL FEMALE METRIC LIGHT |
|---|---|
| Thread size & pitch | M26 - 1.5 |
| Thread physical OD/ID 'D' (mm) | 18 |
| Suits hose ID | 24.5 |
| Cut-off allowance LC (mm) | 50.5 |
| Hex H2 (mm) | 32 |
Specifications from the BOA 1-Piece Fittings catalogue.
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
