3/4" 2SN/R2AT Enduromax 2-Wire Hydraulic Hose - Wrapped Cover
Per metre
$66.04
Skip to product information
3/4" 2SN/R2AT Enduromax 2-Wire Hydraulic Hose - Wrapped Cover
$66.04
inc GST
Shipping calculated at checkout.
3/4" 2SN/R2AT Enduromax 2-Wire Hydraulic Hose - Wrapped Cover
- Part number: SF2SN-12W
Specifications
| Hose ID (in) | 3/4 |
|---|---|
| Hose ID (mm) | 19 |
| Working pressure (psi) | 3100 |
| Working pressure (bar) | 214 |
| Reinforcement | 2 layers |
Specifications from the BOA Hose - High Pressure catalogue (part SF2SN-12).
Features
- Inner tube: Synthetic rubber
- Reinforcement: 2 high-tensile steel wire braid
- Cover: Weather, oil and abrasion resistant synthetic rubber. MSHA cover
- Standards: Non skive. Meets or exceeds SAE J517 100R2, EN853
- Application: High-pressure hose suitable for petroleum-based hydraulic fluids, water-glycol and water-oil fire-resistant fluids, hot oil, grease, lubricants, crude oil, and fuel oils.
- Air/gas use: For air and inert gas applications above 100PSI the cover should be pin pricked
- Temperature range: -40°C to +100°C
- Fittings: Suits 1-Piece K Series & 2-Piece S Series Hosetails
Hydraulic hose from BOA Hydraulics' hose range.
