3/4" JIC Female 90° Compact x 1/2" 1-Piece 1 & 2-Wire Tail
$62.07
inc GST
Shipping calculated at checkout.
3/4" JIC Female 90° Compact x 1/2" 1-Piece 1 & 2-Wire Tail
- Part number: K029-1208
- Series: K029 - JIC Female 90° Compact x 1-2 Wire 1-Piece Tail
- Thread: JIC
Specifications
| Thread / fitting type | JIC FEMALE |
|---|---|
| Thread size & pitch | 3/4" - 16 |
| Nominal pipe size | 1/2" |
| Thread physical OD/ID 'D' (mm) | 17.6 |
| Suits hose ID | 1/2" |
| Cut-off allowance LC (mm) | 23.5 |
| Hex H2 (mm) | 25 |
Specifications from the BOA 1-Piece Fittings catalogue.
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
