36 mm DKOS Male Metric Heavy Straight x 3/4" 1-Piece 1 & 2-Wire Tail
$89.58
inc GST
Shipping calculated at checkout.
36 mm DKOS Male Metric Heavy Straight x 3/4" 1-Piece 1 & 2-Wire Tail
- Part number: K078-3612
- Series: K078 - DKOS Male Metric Heavy x 1-2 Wire 1-Piece Tail
- Thread: Metric
Specifications
| Thread / fitting type | DKOS MALE METRIC HEAVY |
|---|---|
| Thread size & pitch | M36 - 2.0 |
| Thread physical OD/ID 'D' (mm) | 36 |
| Suits hose ID | 3/4" |
| Cut-off allowance LC (mm) | 36.8 |
Specifications from the BOA 1-Piece Fittings catalogue.
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
