Hose 3/8 x ORFS F 13/16 90 DL-63.8mm
$115.03
Skip to product information
Hose 3/8 x ORFS F 13/16 90 DL-63.8mm
$115.03
inc GST
Shipping calculated at checkout.
Hose 3/8 x ORFS F 13/16 90 DL-63.8mm
- Part number: J052-1306L
- Thread: ORFS
Specifications
| Thread / fitting type | ORFS FEMALE |
|---|---|
| Thread size & pitch | 13/16 - 16 |
| Thread physical OD/ID 'D' (mm) | 19.05 |
| Suits hose ID | 3/8" |
Specifications from the BOA 1-Piece Fittings catalogue (part J052-1306).
Features
- Ferrule is pre-crimped to the hose tail, so there is no risk of collar misalignment
- The correct ferrule is always fitted, as it is permanently attached to the hose tail
- Suited to general applications and quick assembly
- Matched to BOA's hose range: K-Series suits 1-2 wire braid hose, J-Series (non-skive) suits 4-6 wire multi-spiral hose
Crimp hose tail fitting from BOA Hydraulics' matched hose and fitting range.
